The 9.25-inch single row LED light bar connects to the light bar mount and offers 1,440 raw lumens. It has a 6,000K color temperature and a 10-30V DC input voltage.
Heise LED Lighting Systems
Metra Electronics HE-SL914
SPECS
Input Voltage: 10-30V DC
Wattage: 18W (6-3W OSRAM LEDs)
Raw Lumens: 1440
LUX @ 10M: 22
Color Temperature: 6000K
Beam Pattern: 90° Flood
CONSTRUCTION
Housing Material: Powder Coated Aluminum
Housing Color: Black
Membrane: Gore™
Lens Material: PC
Mounting Bracket: Side and Bottom Mounting
Mounting: Side and Bottom
Hole Dimensions:
Brackets turned inward – 9”
Brackets turned outward – 11”
Mounting Bolt Drill - .25”
Height of Light Bar Itself: 2”
Depth of Light Bar Itself: 2”
Electronics: Integrated-Epoxy Encapsulated
Hardware: Stainless 316
OPERATION
Operating Temperature: -40 °C to +60 °C
Current Consumption: .9 amps @ 13.8 volts
IP Rating: IP67
Protections: Reverse Polarity
Includes light bar and two L-mounting brackets only
Light bar wiring harness is required, but not included (Sold separately)
On Prowler Pro models use 3436-146 Light Bar Mount, 0486-747 Wiring Harness, and 0486-748 Harness Adapter (Sold separately)
On Wildcat XX use 3436-152 Light Bar Mount, 0486-747 Wiring Harness, & 0486-748 Harness Adapter (Sold separately)
Replaces Part # H654077
Fits Arctic Cat/Textron Models:
2012-2013 Ambush
2014-2017 Ambush iS
2018-2020 Havoc
2018-2019 Prowler EV & EV iS
2019-2024 Prowler Pro & Pro Crew
2017-2020 Stampede
2017-2020 Stampede XTR & 4
2013-2017 Recoil & Recoil iS
2015-2017 Recoil iS Crew
2018-2024 Wildcat XX
(Excludes Wildcat X, 4, Trail, Sport)
Also Fits:
2020-2021 Caterpillar CUV82/102D & CUV85/105D
2019-2020 Cushman Hauler 4x4 & 4x4 Crew
2020 Tracker Off Road SVX1000
2020 Tracker Off Road XTR1000
2020-2023 Tracker Off Road EV & EV iS
2020-2024 Tracker Off Road 800SX & 800SX Crew
Can also be used on just about any model that has room to mount it
| SKU | 654077 |
|---|---|
| Color | Black |
| Replaces Part # | H654077 |
| Prop 65: |
